| 型號 | Model | S PN-1300 | S PN-1650 | S PN-2000 |
| 最大加工寬度 | Max. Machining Width | 1300mm | 1650mm | 2000mm |
| 最短加工長度 | Min. Machining Length | 400mm | 400mm | 400mm |
| 加工厚度 | Machining Thickness | 8-100mm | 8-100mm | 8-100mm |
| 輸送電機功率 | Conveying Motor Power | 1.5kw | 2.2kw | 2.2kw |
| 升降電機功率 | Lifting Motor Power | 1.1kw×2sets | 1.1kw×2sets | 1.1kw×2sets |
| 砂帶傳動電機功率 | Sanding Belt Driving Motor Power | 5.5kw×2sets | 5.5kw×2sets | 5.5kw×2sets |
| 襯帶傳動電機功率 | Lining Belt Driving Motor Power | 3.0kw×2sets | 3.0kw×2sets | 3.0kw×2sets |
| 風機電機功率 | Motor Power of Fan | 7.5kw×1set | 7.5kw×1set | 11kw×1set |
| 總功率 | Total Power | 28.2kw | 28.9kw | 32.4kw |
| 外形尺寸（長×寬×高） | Machine Size(L×W×H) | 2600×3900×1450mm | 2230×4150×1450mm | 2600×4600×1450mm |
| 重量 | Machine Weight | 1800kgs | 2000kgs | 2500kgs |
